V5 Sigmas

The IsoTek V5 Sigmas is a 7-way mains power cleaner for audio, audio-visual and network-based systems, including TVs and projectors. It is designed to serve a complete high-end audio system, with separate power cleaning for each connected component and protection against power surges and voltage spikes.

Building on the EVO3 predecessor, the V5 Sigmas combines 7 dedicated power cleaning circuits in one enclosure. Three high-current outlets use a lighter version of the V5 Titan’s Direct-Coupled circuit to provide ultra-high-current, low-impedance power for amplifiers, subwoofers, active loudspeakers, TVs and projectors. The 4 medium-current outlets are intended for source components, with each socket supplied by its own independent clean power network.

• Suitable for all audio or AV systems
• RFI reduction 80dB
• 7 optimised power cleaning circuits remove Common and Differential Mode mains noise
• 4 independent outlets for source components (10A max each)
• 3 independent high current outlets for power amps, active subwoofers, active loudspeakers, TVs etc. (16A max each)
• 121’500A instantaneous protection
• Fully star-earthed network
• Solid core Ohno Continuous Cast copper silver-plated internal wiring with FEP virtual air dielectric
• System Link outlet for extending the outlets and maintaining a starred earth reference
• Supplied with IsoTek’s EVO3 Premier power cable (1.5m)

The 4 source-component outlets are rated at 10A maximum each, while the 3 high-current outlets are rated at 16A maximum each. A fully star-earthed network and the System Link outlet allow additional outlets to be connected while maintaining a starred earth reference.
