NSC222
The Naim NSC222 brings streaming, internet radio and network audio into a versatile preamplifier, supporting bitrates up to 32bit/284kHz alongside Spotify Connect, TIDAL, Qobuz, AirPlay 2, Chromecast and Roon Ready. Its MM phono input and dedicated headphone technology accommodate vinyl playback and private listening.
Or speak to a specialist, 01202 911886
0% Finance Available
Finance example
£1,140.00 initial 20% deposit then £190.00 per month for 24 months. Other finance terms available. Finance subject to status.
Spread the cost with interest-free monthly payments through Novuna Consumer Finance, subject to status and affordability. Available on qualifying purchases. Terms and conditions apply.
The Naim NSC222 is a versatile streaming preamplifier for the New Classic range, with access to Spotify, TIDAL, Qobuz and a very large number of online radio stations. It handles bitrates of up to 32bit/284kHz.
For vinyl playback, the NSC 222 includes a moving-magnet phono input. Headphone listening is supported by Naim amplifier-DAC technology inherited from the Uniti Atom Headphone Edition, which has received several awards around the world.
The NSC222 uses Naim’s latest streaming platform, developed by Naim’s engineers in Salisbury. It provides access to Spotify Connect, Apple Music, TIDAL, TIDAL Connect, Qobuz, AirPlay 2, Chromecast, UPnP™ servers, a USB key and Roon Ready functionality, alongside online radio stations and other music services.
Naim’s engineers developed simple, carefully arranged circuits under the guidance of the company’s Technical Director. The design combines these circuits with Naim’s DR technology to provide a stable, fluid power supply. The NSC 222 uses high-quality components and is subject to precise measurements during development.
| USB | 2 x USB Type A socket (front and rear - 1.6A charge) |
|---|---|
| Digital (S/PDIF) | 2 x Optical TOSLINK (up to 24bit/96kHz) 1 x coaxial RCA (up to 24bit/192kHz, DoP 64Fs) 1 x coaxial BNC (up to 24bit 192kHz, DoP 64Fs) |
| Audio Input | 1 x moving magnet phono 1 x 8-pin DIN (compatible with 5-pin DIN cables) 1 x RCA stereo pair Line level inputs (RCA/DIN): Impedance 47k, 2.2V typical, 7.5Vrms Max 8 pin DIN has +/-18V for compatible external phono stages such as Solstice NVC TT Compatible with 5 pin DIN MM phono: 47k/470pF, 5mV, 23dB overload (75mV max) |
| Distortion | MM: < noise floor Line: 0.0025% @2.2V input volume at 0dB, 1kHz (Line: 0.015% @2.2V input volume at 0dB, 20kHz) Digital: 0.0035% @0dBFS volume at 0dB, 1kHz |
| Digital level | 2.1V at 0dBFS volume at 0dB |
| Audio Outputs | Analogue 1 x XLR pair (Stereo XLR balanced impedance 7Vrms max) 1 x RCA pair (Stereo RCA 7Vrms max) 1 x 6.35mm headphone jack (Headphone 1.5W into 16) |
| Frequency Response | MM: -3dB at 10Hz, RIAA +/-0.1dB Line: 3Hz to 40kHz -3dB Digital: 3Hz to 27kHz -3dB |
| Audio Formats | WAV - up to 32bit/384kHz FLAC and AIFF - up to 24bit/384Hz ALAC (Apple Lossless) - up to 24bit/384Hz MP3 - up to 48kHz, 320kbit (16 bit) AAC - up to 48kHz, 320kbit (16 bit) OGG and WMA - up to 48kHz (16 bit) DSD - 64 and 128Fs M4A - up to 48kHz, 320kbit (16 bit) Gapless playback supported on all formats |
| Weight | 24.25lbs (11kg) |
| Dimensions (HxWxD) | 35/8x17x121/2" (9.15x43.2x31.75cm) |
| Delivery | UK delivery available |
|---|---|
| Lead time | Agreed personally, finish and stock dependent |
| Warranty | 2 years warranty |
| Trade-in | Part exchange available (subject to conditions) |
