Masterclass PA-4
The Sugden Masterclass PA-4 brings transparency, natural tonality and musical realism to vinyl playback, with 2 moving-coil inputs, 1 moving-magnet input and cartridge-loading options for precise matching. Its Class A stages use current-feedback for MC and voltage-feedback with RIAA equalisation for MM, supported by a current-shunt power supply and gold-plated circuit boards.
Or speak to a specialist, 01202 911886
0% Finance Available
Finance example
£558.80 initial 20% deposit then £124.18 per month for 18 months. Other finance terms available. Finance subject to status.
Spread the cost with interest-free monthly payments through Novuna Consumer Finance, subject to status and affordability. Available on qualifying purchases. Terms and conditions apply.
The Sugden Masterclass PA-4 is a phono amplifier for vinyl systems, with support for moving-coil and moving-magnet cartridges. It has 2 moving-coil inputs and 1 moving-magnet input, together with virtually unlimited cartridge-loading options. Each unit can be factory configured to match the cartridge precisely.
The moving-coil stage uses a Class A current-feedback circuit. The moving-magnet stage uses a Class A voltage-feedback design, with RIAA equalisation incorporated into the negative-feedback loop. DC servo circuitry keeps the musical signal directly coupled from the moving-coil input through to the final output.
Sugden treats the power supply as an integral part of the amplifier, so the PA-4 uses a current-shunt power supply with a specially designed voltage regulator. This is intended to maintain low impedance at higher frequencies.
The Sugden PA-4 is hand-assembled using carefully selected, high-quality components on gold-plated circuit boards designed for long-term stability. Its design is intended to provide transparency, natural tonality and musical realism while preserving the character of the recording.
| Inputs ​ | Two moving coil, moving magnet |
|---|---|
| Outputs | Two line level |
| Input Sensitivity | Moving magnet 3.5mV |
| Loading | Moving magnet 57K |
| Frequency Response | +/-0.3dB 30Hz-30kHz |
| Gross Weight (packed) | 6kgs |
| Dimensions | 110 x 430 x 330mm (hwd) |
| Delivery | UK delivery available |
|---|---|
| Lead time | Agreed personally, finish and stock dependent |
| Warranty | 5 years warranty |
| Trade-in | Part exchange available (subject to conditions) |
