M28
The Bricasti M28 delivers 200 watts into an 8 ohm load with flat response and very low distortion. Its balanced differential architecture supports fast, articulate low-frequency performance, while 18 dB stepped gain attenuation allows level matching with different sources or listening spaces.
Or speak to a specialist, 01202 911886
0% Finance Available
Finance example
£3,600.00 initial 20% deposit then £480.00 per month for 30 months. Other finance terms available. Finance subject to status.
Spread the cost with interest-free monthly payments through Novuna Consumer Finance, subject to status and affordability. Available on qualifying purchases. Terms and conditions apply.
The M28 is designed to provide the current needed to control speakers through demanding musical passages. It is conservatively rated at 200 watts into an 8 ohm load, with flat response and very low distortion. Low-frequency performance remains fast and articulate, including at the speaker’s resonant peak.
A balanced differential structure reduces the stress on the M28 amplifier’s internal elements. Used with the balanced structure of the Bricasti M1 digital to analogue converter, the M28 forms a balanced differential signal path from source to speaker. The M28 also provides 18 dB of stepped gain attenuation for level matching with different audio sources or listening spaces. An RS232 link conveys status information for monitoring several system functions.
The M28 combines its mechanical and electronic design in a precisely engineered amplifier. Its milled aluminium chassis is manufactured to exacting tolerances, with each electronic element positioned within a dedicated location. Mass and passive ventilation are used to distribute heat evenly and maintain a cool-touch chassis under load. Electronic and thermal design, together with detailed analysis of each completed system, support the specified performance.
| Power | 200W into 8 ohms, 400W into 4 ohms, 800W into 2 ohms. |
|---|---|
| Frequency response | 10hz-150kHz, within 0.5db. |
| Signal to Noise | greater than 95db at full rated. |
| Inputs | XLR connector 200k ohm impedance. RCA connector 100k ohm impedance. |
| Weight | 85 lbs |
| Power consumption | 60W standby, 2W idle. |
| Delivery | UK delivery available |
|---|---|
| Lead time | Agreed personally, finish and stock dependent |
| Warranty | 2 years warranty |
| Trade-in | Part exchange available (subject to conditions) |
