DAC3 Module
The Gryphon DAC3 Module adds 5 digital inputs to the Diablo 333 integrated amplifier, accepting PCM through USB, AES, S/PDIF and TOSLINK, with DSD available via USB. The Diablo 333 display shows the selected input’s sampling frequency, PCM or DSD format and digital filter setting, with 7 PCM roll-off filters available.
Or speak to a specialist, 01202 911886
0% Finance Available
Finance example
£1,390.00 initial 20% deposit then £231.67 per month for 24 months. Other finance terms available. Finance subject to status.
Spread the cost with interest-free monthly payments through Novuna Consumer Finance, subject to status and affordability. Available on qualifying purchases. Terms and conditions apply.
The Gryphon DAC3 Module is a digital-to-analogue converter module for the Diablo 333. Its display shows the selected digital input sampling frequency, PCM or DSD format and digital filter setting.
- True Dual Mono discrete Class A analogue configuration
- Zero global negative feedback
- Sabre High-Performance ES9039PRO D/A converter
- USB input compatible with the following audio formats via PC, Mac or Linux: PCM at 44.1, 48, 88.2, 96, 176.4, 192, 352.8 and 384 kHz, up to 32 bits. DSD via USB: DSD64, DSD128, DSD256 and DSD512
- XLR and BNC inputs compatible with PCM at 22.05, 24, 32, 44.1, 48, 64, 88.2, 96, 176.4 and 192 kHz, up to 32 bits
- TOSLINK input compatible with PCM at 22.05, 24, 32, 44.1, 48, 64, 88.2 and 96 kHz, up to 24 bits
- Seven user-selectable PCM digital roll-off filters
- Temperature-compensated, ultra-low-jitter crystal oscillator with better than 5 parts per million accuracy
- 12.5 Farad Super-Capacitor power supply for the USB module, acting as a true battery supply
- First-order PCM analogue filters and second-order DSD analogue filters with polypropylene capacitors
- Analogue output stages with ultra-low-noise +/- 22VDC regulated voltage supplies for analogue THD and noise suppression
- Multiple local voltage regulators for digital noise suppression
- Separate left and right channel ultra-low-noise power supplies for the analogue section of the ES9039PRO DAC
- Ultra-short signal path
- Minimal internal wiring
- Six-layer printed circuit boards
- PCB-mounted input sockets eliminate wiring and shorten the signal path
- Gold-plated Neutric XLR socket for 1 balanced 110Ω AES source
- Gold-plated 75Ω BNC sockets with Teflon insulation for 2 S/PDIF sources
- 1 TOSLINK optical fibre input
- Designed and built in Denmark
| Type | DACs |
|---|---|
| Finish | Multiple finishes available |
| Warranty | 2 years |
| Condition | Brand new, boxed |
| Delivery | UK delivery available |
|---|---|
| Lead time | Agreed personally, finish and stock dependent |
| Warranty | 3 years warranty |
| Trade-in | Part exchange available (subject to conditions) |
