BP-2
The Bryston BP-2 supports moving magnet cartridges, with switchable capacitive loading between 100µF and 400µF, while the MM/MC version adds compatibility with low-output moving coil cartridges through ultra-low-distortion, wide-bandwidth step-up transformers. Its frequency response is +/-0.1dB from 20Hz to 20kHz with inverse RIAA EQs, and it runs from a Bryston MPS-2 or PS-3 DC power supply.
Choose the configuration to see its price.
Or speak to a specialist, 01202 911886
Available as either an MM (moving magnet) model or an MM/MC model with moving coil compatibility, the BP-2 is suitable for most current cartridges. Both versions provide switchable capacitive loading for moving magnet cartridges.
The MM/MC version incorporates a pair of ultra-low-distortion, wide-bandwidth step-up transformers, also used in the TF-2, for compatibility with low-output moving coil cartridges. The transformers can be factory wound to provide an additional 20dB or 31dB of gain.
The BP-2 can be powered by an existing Bryston MPS-2 DC power supply or the PS-3 DC power supply.
Features:
MM gain is 41dB, MM/MC-20 gain is 61dB, and MM/MC-30 gain is 72dB
Switchable capacitive loading between 100µF and 400µF for MM cartridges
Frequency response of +/-0.1dB from 20Hz to 20kHz with inverse RIAA EQs
Powered by an outboard Bryston MPS-2 or Bryston PS-3 DC power supply
Steel chassis and top.
Options:
Available with a silver or black faceplate
Available in MM only or MM/MC versions
Phono power cable for the MPS-2 power supply, purchased separately
| BP2-MM Moving Magnet Phono Preamplifier | |
|---|---|
| Frequency Response (using RIAA Inverse EQ) | 20 Hz - 20kHz ± 0.1 dB |
| Gain | 41 dB @ 1kHz |
| Sensitivity | 5 mV |
| Distortion 20Hz to 20kHz | 0.005% THD+N or IMD |
| Noise A Weighted | 80dB ref. 5 mV input |
| BP2-MM/MC Moving Magnet / Moving Coil Phono Preamplifier | |
| Frequency Response (using RIAA Inverse EQ) | 20 Hz - 20kHz ± 0.1 dB |
| Gain (dB) @ 1kHz | BP2-20 MC Mode: 61 |
| Distortion | MM Mode: ≤0.005% THD+N or IMD @ 20Hz-20kHz |
| Noise A Weighted | 80dB ref. 5 mV input |
| Weight | 3.8 lbs; 1.75 kg |
| Delivery | UK delivery available |
|---|---|
| Lead time | Agreed personally, finish and stock dependent |
| Warranty | 20 years warranty |
| Trade-in | Part exchange available (subject to conditions) |
