BDA-3
The Bryston BDA-3, a digital-to-analogue converter, uses re-sampling and re-clocking to process digital sources while retaining native rates unless user-selectable up-sampling is applied. Its asynchronous USB inputs decode DSD-256 and PCM up to 384kHz/32-bit, while 10 inputs include HDMI, AES/EBU, optical, coaxial and USB connections.
Choose the option to see its price.
Or speak to a specialist, 01202 911886
0% Finance Available
Finance example
£900.00 initial 20% deposit then £200.00 per month for 18 months. Other finance terms available. Finance subject to status.
Spread the cost with interest-free monthly payments through Novuna Consumer Finance, subject to status and affordability. Available on qualifying purchases. Terms and conditions apply.
The Bryston BDA-3 is a digital to analogue converter designed for use with sources including Bryston BDP digital music players, computers, music servers and CD players. It is intended for digital audio systems requiring high performance.
The BDA-3 uses re-sampling and re-clocking of the digital input signal. Apart from user-selectable up-sampling, it does not convert the signal to another format or re-sample it at a non-native rate. Compared with the BDA-2, it adds PCM playback up to 384kHz/32-bit resolution and full DSD support. The BDA-3 decodes up to DSD-256 through its asynchronous USB inputs and accepts SACD input via HDMI. It has 10 separate inputs, comprising 4 2-channel HDMI inputs, asynchronous USB, AES/EBU, TOSLINK and digital coaxial connections. A network module provides control via TCP/IP and RS-232.
Inputs: 4x HDMI, 2x USB 2.0 Type B, 2x S/PDIF (1x BNC, 1x RCA), 1x Optical (TOSLINK), 1x AES/EBU
Outputs: HDMI, RCA, XLR
Control: TCP/IP, IR, DC, RS-232
Features:
Dual 32-bit AKM DAC ICs
Discrete Class A analogue output stage
Independent analogue and digital signal paths
Independent power supplies
Support for different PCM and DSD resolutions
HDMI video pass-through with audio out (4K video pass-through)
Options:
Available with silver or black faceplate
17” or 19” faceplate available
Rack-mountable option available (2U)
BR2 remote control available
| Output Voltage | Balanced: 4.0V; Single Ended: 2.0V |
|---|---|
| Frequency Response | 0Hz - 20kHz: ± 0.1dB |
| Noise | Balanced Out: -140dB; Single Ended Out: |
| IMD | ≤0.0003% |
| THD + Noise | 20Hz-20kHz :≤0.002% |
| Dimensions | Inches: 17 or 19 W x 3.325 H x 11.53 D; Cm: 43. or 48.3 W x 8.5 H x 29.3 D |
| Weight | 4kg | 8.75lbs |
| Delivery | UK delivery available |
|---|---|
| Lead time | Agreed personally, finish and stock dependent |
| Warranty | 5 years warranty |
| Trade-in | Part exchange available (subject to conditions) |
