AVR20

The Arcam AVR20 is a 16-channel audio/visual receiver for home cinema and music systems. It supports Dolby, DTS, Auro-3D and IMAX Enhanced codecs, with Dolby Atmos, DTS:X and AURO-3D decoding.

The AVR20 uses Class AB amplification and includes 16-channel Dirac Live room correction. Dirac Live Bass Control is also supported and is available through the Dirac website. It combines measurement and placement data from the subwoofers and main speakers to determine how bass is distributed throughout the room.

Digital conversion is handled by dual ESS 9026PRO DACs with ESS reference voltage regulators. Streaming is available from a mobile device through Apple AirPlay2 or Google Chromecast, while Bluetooth aptX HD, MQA support and Roon Ready compatibility provide further playback options. The receiver also provides Wi-Fi, Ethernet, RS232 and IR control.

• 16 Channels of Dolby Atmos, DTS:X & AURO-3D decoding
• Dual ESS 9026PRO audiophile DACs with ESS reference voltage regulators
• 7 Channels of high power Class G amplification
• Includes Dirac Live® room correction
• Ready for Dirac Live Bass Control
• 7 HDMI inputs, 3 HDMI outputs inc Zone 2
• eARC compatible
• HDMI2.0b with HDCP2.2
• 4K (UHD) supported
• Apple® Airplay2
• Google Chromecast® built-in
• Bluetooth aptX®HD
• Supports MQA
• Roon Ready
• Wi-Fi / Ethernet, RS232 and IR control
