805 D4 Signature
Bowers & Wilkins 805 D4 Signature places a Solid Body Tweeter-on-Top above its compact stand-mount enclosure, using a Diamond Dome tweeter for accurate high-frequency reproduction. Its Continuum Cone and rear-mounted crossover assemblies on rigid aluminium spines support an open, neutral presentation with precise, transparent voices and instruments.
Or speak to a specialist, 01202 911886
0% Finance Available
Finance example
£2,350.00 initial 20% deposit then £313.33 per month for 30 months. Other finance terms available. Finance subject to status.
Spread the cost with interest-free monthly payments through Novuna Consumer Finance, subject to status and affordability. Available on qualifying purchases. Terms and conditions apply.
Compact and powerful
The 805 D4 Signature is a compact, powerful stand-mount loudspeaker. It incorporates optimised technologies including the Diamond Dome tweeter and Solid Body Tweeter-on-Top. Its compact form is paired with a considered finish.
Diamond Dome tweeter
The ultra-stiff Diamond Dome tweeter combines low mass, exceptional stiffness and accuracy. Introduced 15 years ago, this tweeter dome technology remains a central part of the design.
All-new tweeter grille
The Solid Body Tweeter-on-Top housing has an elongated form, a longer tube-loading system and a newly designed tweeter grille. This arrangement is intended to provide a more open, free presentation at high frequencies.
Upgraded crossover
The 805 D4 Signature uses upgraded rear-mounted crossover assemblies fitted to rigid aluminium spines. This isolates the sensitive capacitors from air pressure within the enclosure, while the aluminium structure also acts as an effective heatsink during use.
Continuum™ Cone
Its composite Continuum™ Cone avoids the abrupt changes in behaviour that can affect conventional drive units. The 805 D4 Signature is designed for an open, neutral presentation, with voices and instruments reproduced with precision and transparency.
| Technical features | Diamond tweeter Solid Body Tweeter-on-Top Continuum™ cone bass/midrange Matrix™ Anti-Resonance plug Flowport™ |
|---|---|
| Drive units | 1x ø25mm (1in) Diamond Dome high-frequency 1x ø165mm (6.5in) Continuum™ cone bass/midrange |
| Frequency range | 6dB 34Hz to 35kHz |
| Harmonic distortion | 2nd and 3rd harmonics (90dB, 1m on axis) |
| Frequency response | 42Hz to 28kHz ±3dB |
| Sensitivity | 88dB spl (2.83Vrms, 1m) |
| Dimensions | Height: 440mm (17.3in) / Width: 240mm (9.4in) / Depth: 373mm (14.7in) |
| Weight | 15.55kg (34.3 lb) |
| Delivery | UK delivery available |
|---|---|
| Lead time | Agreed personally, finish and stock dependent |
| Warranty | 2 years warranty |
| Trade-in | Part exchange available (subject to conditions) |
